Salient Features

• Smart charts with random display function for all optotypes
• 1% Contrast sensitivity adjustment for all optotypes
• Adaptable to smaller rooms with precise adjustment for distance
• External USB port for viewing your own images and videos
• 2 Min. Speedy refraction using the 4 navigation keys
• 160+ Patient education charts for various eye diseases
• 60+ HD videos for patient education
• Extensive display models for optotypes
• Reverse mode for all charts
• External 3.5mm audio jack for audio out
• Compensation for red green filter
• Feather touch remote control with direct commands for all tests
• No moving parts

Technical specifications

• LCD Type
• Luminance
• Remote Control
• Working distance
• Connections
• Power Requirements
• Power Consumption
• Unit Weight
• Gross Weight
• Unit Dimensions
• Package Dimensions

•   : 22" LED Display
•   : 200 cd/m2
•   : Infrared
•   : 2m ~ 6m
•   : Audio, USB
•   : 110-239 VAC, 50/60Hz
•   : 35W
•   : 4.2 kg
•   : 4.4 kg
•   : 52.5 x 33 x 6.5 cm
•   : 58.5 x 42 x 14.0 cm

Standard Tests

• Snellen
• Logmar
• Isihara (20 Plates)
• Maddox
• Worth Fur Dots
• Astigmatism
• Contrast sensitivity
• Duochrome
• Cross Cylinder

Figures for children

• Display modeds
• Single character
• Single line
• Single column
• Black in white
• Multi Line

Optotypes

• Sloan Letters
• Numbers
• Tumbling E
• Landolt Rings

Technical specifications

• 24 inches Flat Panel Screen
• High resolution 1280 X 1080
• Chart size automatically calibrates to the working distance
• Wireless remote controlled
• Wide range of Optotypes,Tumbling E's, Children's,
  Red/Green test, Snellen, Astigmatism Testing.
• 20/400 - 20/10 VA
• Four different lines 20/20
• Red / Green test on all optotypes, Snellen, Numbers, Children's.
• Do it your self installation
• On screen instructions manual
• 3 minutes or less calibration to room size
